Philips Advance Fluorescent Ballast - 13W | 120-277V AC | Programmed Start

ICF-2S13-M1-BS-QS is the Philips Advance Fluorescent Ballast. This model is a replacement ballast for the matching fluorescent lamp circuit. Select it from the lamp schedule inside the existing fixture. The listed lamp configuration is 1 or 2 X 13W CFL, which should be checked as a complete lamp-and-count combination. This is the programmed start version, so the fixture wiring and lampholder arrangement must suit that starting method.

Plan the electrical connection around this model’s 120-277V AC rating. This version lists length 4.98 in., width 2.40 in., height 0.98 in. Those measurements help check physical fit at the ballast compartment. Follow the wiring diagram for this model when making the replacement connections.

Buying tip: Match the lamp designation, number of lamps and supply voltage to the existing ballast.
