Philips Advance Fluorescent Ballast - 26W | 120-277V AC | Programmed Start

ICF2S26-H1-LD is the Philips Advance Fluorescent Ballast. This model is a replacement ballast for the matching fluorescent lamp circuit. Select it from the lamp schedule inside the existing fixture. The listed lamp configuration is 1 or 2 X 26W CFL, which should be checked as a complete lamp-and-count combination. The programmed start starting arrangement is part of the compatibility check for the installed lamp circuit.

Plan the electrical connection around this model’s 120-277V AC rating. Compare length 4.98 in., width 2.40 in., height 0.98 in. with the available space for the ballast compartment, especially when retaining an existing enclosure or shade. Follow the wiring diagram for this model when making the replacement connections.

Buying tip: Match the lamp designation, number of lamps and supply voltage to the existing ballast.
