Philips Advance T8 Fluorescent Ballast - 120V AC | Dimmable | Programmed Rapid Start

REZ-132-SC-35M (191056) is the Philips Advance T8 Fluorescent Ballast. This model belongs in a fluorescent lighting system with the lamp configuration stated for this ballast. The 1 X F32T8 operating configuration distinguishes this ballast from versions intended for a different lamp count. Its specified starting method is programmed start; compare it with the existing circuit rather than relying on the housing dimensions alone. When comparing replacements, note the 0.88 ballast factor as well as the lamp and supply ratings.

Plan the electrical connection around this model’s 120V AC rating. For the ballast compartment layout, allow for the listed length 9.50 in., width 1.70 in., height 1.18 in. and the installation clearances required by its instructions. Follow the wiring diagram for this model when making the replacement connections.

Buying tip: Match the lamp designation, number of lamps and supply voltage to the existing ballast.
