Philips Advance T8 Fluorescent Ballast - 120V AC | Dimmable | Programmed Rapid Start - REZ-3S32-SC-35M (182204)

The Philips Advance T8 Fluorescent Ballast, model REZ-3S32-SC-35M (182204), is the component described here. This model is a replacement ballast for the matching fluorescent lamp circuit. Select it from the lamp schedule inside the existing fixture. It is specified for 3 X F32T8; preserve the required lamp type and quantity when selecting the ballast. Its specified starting method is programmed start; compare it with the existing circuit rather than relying on the housing dimensions alone. The listed ballast factor is 0.88, which is relevant when comparing the output of the same lamps on different compatible ballasts.

The 120V AC supply specification must match the circuit serving this model. For the ballast compartment layout, allow for the listed length 9.50 in., width 1.70 in., height 1.18 in. and the installation clearances required by its instructions. Follow the wiring diagram for this model when making the replacement connections.
