Philips Advance T8 Fluorescent Ballast - 120-277V AC | Programmed Rapid Start

IOP-4PSP32-SC-35M (107201) is the Philips Advance T8 Fluorescent Ballast. When servicing a socketed fluorescent fixture, compare this model against the lamp schedule and supply before ordering. It is specified for 4 X F32T8; preserve the required lamp type and quantity when selecting the ballast. The programmed start starting arrangement is part of the compatibility check for the installed lamp circuit. The listed ballast factor is 0.88, which is relevant when comparing the output of the same lamps on different compatible ballasts.

The 120-277V AC supply specification must match the circuit serving this model. Compare length 9.50 in., width 1.70 in., height 1.18 in. with the available space for the ballast compartment, especially when retaining an existing enclosure or shade. Follow the wiring diagram for this model when making the replacement connections.

Buying tip: Match the lamp designation, number of lamps and supply voltage to the existing ballast.
